Mini Bluetooth Module ZORY-A2210 (Gen 4) / ZORY-A2212 (Gen 4)
Overview: Plays phone music via Bluetooth; control volume, track, play/pause from phone.
Product Details
| Product Size: | 60×60×10mm (L×W×H) |
|---|---|
| Operating Voltage: | DC12V/DC24V |
| Bluetooth: | Bluetooth 5.1, dual-mode, 2.4GHz |
| Audio: | Power: 4.5W×2, SNR 80dB, impedance 4Ω, THD ≤10% |
| BT Range: | 10 m |
| Optional: | 1. BT name & password customizable & numbered (alphanumeric) |
| 2. Compatible with any touch switch; keys control BT on/off, etc. | |
| 3. Multiple speaker sizes available — see Bluetooth Series or spec sheets. | |
| 4. … | |
| [Note] Custom logic available; final per samples. |
